Ultraviolet curing lamp Curing Conveyor Dryer for UV Screen Printing
Ultraviolet curing lamp Curing Conveyor Dryer for UV Screen Printing Ultraviolet curing lamp Curing Conveyor Dryer for UV Screen Printing Ultraviolet curing lamp Curing Conveyor Dryer for UV Screen Printing Ultraviolet curing lamp Curing Conveyor Dryer for UV Screen Printing

Ultraviolet curing lamp Curing Conveyor Dryer for UV Screen Printing

Item No.: HR-UV750

TYPE HR-UV400 HR-UV750 HR-UV900 HR-UV1000 HR-UV1200
Convey belt width (mm) 380 730 880 980 1180
Effective range (mm) 400 750 900 1000 1200
Max thickness of cured (mm) 40 40 40 40 40
Conveying speed (m) 2~20 2~20 2~20 0~25 2~20
Power(P/V/Hz) 3/380/50 3/380/50 3/380/50 3/380/50 3/380/50
UV lamp (KW*pcs) 3 5.6*2 5.6*2 5.6*2 5.6*2
Driving power (W) 60 90 90 120 120
Total power(KW) 3.4 12.1 12 16.5 17
Size (L*W*H) 1700*700*1200 2550*1050*1450 2550*1200*1600 2550*1200*1600 4050*1460*1600
Weight (Kg) 250 350 420 450 580

INQUIRY
Description


TYPE HR-UV400 HR-UV750 HR-UV900 HR-UV1000 HR-UV1200
Convey belt width (mm) 380 730 880 980 1180
Effective range (mm) 400 750 900 1000 1200
Max thickness of cured (mm) 40 40 40 40 40
Conveying speed (m) 2~20 2~20 2~20 0~25 2~20
Power(P/V/Hz) 3/380/50 3/380/50 3/380/50 3/380/50 3/380/50
UV lamp (KW*pcs) 3 5.6*2 5.6*2 5.6*2 5.6*2
Driving power (W) 60 90 90 120 120
Total power(KW) 3.4 12.1 12 16.5 17
Size (L*W*H) 1700*700*1200 2550*1050*1450 2550*1200*1600 2550*1200*1600 4050*1460*1600
Weight (Kg) 250 350 420 450 580
